Description
twin hammer mechanism
compressed air inlet: 1/4"
recommended hose internal Ø: 10 mm
vibration level: ahd = 7.7 m/s² K = 1.25 m/s²
Technical data
Max. drive speed 8000 rpm
Output profile External square
Drive profile size, metric 12,5 mm
Drive profile size, inch 1/2 "
Min. working speed 68 Nm
Max. working speed 786 Nm
Max. loosening torque 1756 Nm
Sound pressure level 92,8 dB(A)
Sound power level 103,8 dB(A)
Operating pressure 6,3 bar
Air consumption 113 l/min
Hose diameter 10 mm
Length 187 mm
Weight 1,9 kg
